SX-160DA / SX-120DA DUAL WIRE POCKET SPRING MACHINE







With Red Dot : Wire Diamater 2.2MM

Without Red Dot : Wire Diamater 1.8MM



Technical Data

Spring Type

Barrel or Cylindrical

Capacity

160/120 Springs per min

Spring Waist ext Dia

Φ45-Φ70MM  ( >Φ70 MM on request )

Steel Wire Gauge

Φ1.4-Φ2.3MM( <Φ1.4MM  on request)

Pocket Height

70-220MM(<70 or >220MM on request)

Fabric Width

≤650MM

Fabric Thickness

≥60G/M2

Fabric Diameter

≤1M

Main Drive Power

30KVA

Air Consumption

10M3/H

Weight

4830KG

Power Requirement

380V,3 Phase,50-60HZ

(Option:415V-480V,,220V)
